• Small size, fits in your palm
• User temperature calibration
• Single molded chamber, no cracks or welds
• PTFE coated chamber resists stains
• Can be used as a mini water bath or bead bath
• Outstanding heating rate
• Different sizes of heating block available for selection
• Clear cover to ensure temperature uniformity
• Optional in-car power adaptor provides portability on the road
Cat. No. |
MD-MINI |
Display |
LED |
Power |
50W |
Dimension |
(WxLxH) 6.02"x4.92"x3.82" (153x125x97mm) |
Controller |
Digital microprocess controller |
Heating chamber |
Molded waterproof aluminum alloy coated with PTFE |
Temperature control range |
5°C above ambient to 100°C |
Temperature increment |
0.1°C |
Temperature uniformity at 37°C |
± 0.20°C |
Temperature accuracy at 37°C |
± 0.25°C |
Temperature calibration |
Yes |
Timer |
9999 (min) / Continuous |
Safety |
Leak proof heating chamber |
Over temperature protection |
|
Operating temperature |
Ambient to 40°C |
Special feature |
Used as water bath or bead bath |
Block material |
Aluminum alloy |
Block type |
Standard and customized type are available |
Rated voltage |
100V-240V |
Weight |
Approx. 1.3lb (0.6kg) |
Blocks |
|
Block material |
Aluminum alloy |
Dimension |
(WxLxH) 1.85"x2.80"x1.26" (47x71x32mm) or 1.85"x2.80"x2.95" (47x71x75mm) |
Block lifter well |
Yes |
Thermometer well |
Yes |
